| Range | Resolution | Test current | Accuracy |
|---|---|---|---|
| 0…999.9 μΩ | 0.1 μΩ | 10 A | ±(0.2% m.v. + 2 digits) |
| 1.0000…1.9999 mΩ | 0.0001 mΩ | 10 A | ±(0.2% m.v. + 2 digits) |
| 2.000…19.999 mΩ | 0.001 mΩ | 10 A | ±(0.2% m.v. + 2 digits) |
| 20.00…199.99 mΩ | 0.01 mΩ | 10 A / 1 A | ±(0.2% m.v. + 2 digits) |
| 200.0…999.9 mΩ | 0.1 mΩ | 1 A / 0.1 A | ±(0.2% m.v. + 2 digits) |
| 1.0000…1.9999 Ω | 0.0001 Ω | 1 A / 0.1 A | ±(0.2% m.v. + 2 digits) |
| 2.000…19.999 Ω | 0.001 Ω | 0,1 A | ±(0.2% m.v. + 2 digits) |
| 20.00…199.99 Ω | 0.01 Ω | 10 mA | ±(0.2% m.v. + 2 digits) |
| 200.0…1999.9 Ω | 0.1 Ω | 1 mA | ±(0.2% m.v. + 2 digits) |
„m.v.” - measured value.
Other technical specification:
- insulation typeaccording to EN 61010-1: double
- measurement category: III 600 V acc. to EN 61010-2-030:2011
- ingress protection according to EN 60529:
- with closed housing: IP67
- with open housing, powered from the battery pack, installed plugs: IP54
- with open housing, powered from mains and/or without plugs: IP40
- protection against external voltage: up to 600 V AC for 10 s
- power supply to battery charger: 90 V…265 V/50 Hz…60 Hz, 2 A
- battery charging time: approximately 3.5 hours
- number of measurements (of resistive objects) with 10 A current performed when powered from the: 700…800 depending on the ambient temperature
- maximum wire resistance for 10 A current: 300 mΩ
- accuracy of measuring current setting: ± 10%
- time of performing the resistance measurement:
- with selected resistive object type and bidirectional current flow: 3 s
- with selected inductive object type, dependent on the resistance and inductance of the object: 5 s or more
- operating temperature: -10°C…+50°C / 14°F…122°F
- charger operating temperature: 0°C…+45°C / 32°F…113°F
- storage temperature: -20°C…+60°C / -4°F…+140°F
- humidity: 20%…90%
- reference temperature: +23°C ± 2°C / 73.4°F ± 3.6°F
- reference humidity: 40%…60%
- temperature coefficient: ±0.01% of d.v./°C ± 0.1 digit/°C (“d.v.” - displayed value)
- time to AUTO-OFF: 5…45 minutes or option not active, depending on the setting
- TFT graphic display: 800 x 480 pixels
- interface standard: USB, LAN, Wi-F
- quality standard: design and manufacturing are ISO 9001 compliant
- the product meets the EMC requirements (emission for industrial environment) according to: PN-EN 61326-1 i PN-EN 61326-2-2
- compliance with FCC Rules: Class A digital device
